Bins Identification ISO18000-6C RFID UHF Plastic Seal Tag

Product name: UHF Cable Tie Tag
Model No. : Seal tasgs-01
Frequency:HF/UHF
Size: 300*30 mm,328*28 mm, 448*28 mm
Material: ABS Nylon
Optional color: Red,blue White,etc.
Applications: Cargo Box Managment, Cargo Tracking, Etc.

Bins Identification ISO18000-6C RFID UHF Plastic Seal Tag

ISO18000-6C UHF RFID seal tag for container/ bins identification

Description

RFID cable seal tags combines the mechanical security of traditional CABLE SEAL product together with the electronic security offered by the latest radio frequency-based automatic identification (RFID) techniques.
RFID Seal Tag transponders are ideal for sealing commercial containers – bags, bins or boxes – to prevent unauthorized access to contents while in storage or during distribution.
Seal Tag units integrate powerful RFID chips with high durability components, and secure, tamper-evident fasteners. Access to a sealed container’s contents requires severing a tag’s cable tie or wire loop – or breaching of the container itself – providing clear evidence of tampering.
UHF Seal Tag closures can be identified from up to 5 m, enabling entire loads of sealed containers to be read as trucks pass through stationary readers.
Bins Identification ISO18000-6C RFID UHF Plastic Seal Tag 0
Features

  • Waterproof, Anti Collision, Corrosion, Durability

  • Flip latch location, Cable tie tape insert will not exit, Excellent locking effect

  • Chip in the label binding external position, Not affected by the strapped object, Stable reading


Specifications

MaterialABS Nylon
Dimension45CM (Customized size is available)
Slot Size/Flag Size: 90*28mm
Bundle Length (Max): 35cm
ColorBlue or customized
RF ProtocolISO14443A, EPC/ISO18000-6C
Reading Distance2cm-5m
Break Strength800N
Humidity EnvironmentSuitable for indoor and outdoor use dirt, dust, and water resistant
Available craftsSilkscreen printing, series number, barcode, laser engraving
Chip AvailableHF/UHF
ApplicationsWarehouse, airport, logistic, bank, etc.
Lead time7-10 working days
Sample AvailabilityFree samples are available upon request
CertificatesCE, FCC, RoHS


Applications:

  • Cable and wire identification

  • Sealing commercial containers tracking

  • Logistics

  • Trucks tracking

  • Bins identification

Bins Identification ISO18000-6C RFID UHF Plastic Seal Tag 1

Our Services
1. Warranty: 1 years
